GCC: Optimizing Linux, the Internet, and Everything

6763

Software is useless if computers can’t run it. Even the most talented developer is at the mercy of the compiler when it comes to run-time performance – if you don’t have a reliable compiler toolchain you can’t build anything serious. The GNU Compiler Collection (GCC) provides a robust, mature and high performance partner to help you get the most out of your software. With decades of development by thousands of people GCC is one of the most respected compilers in the world. If you are building applications and not using GCC, you are missing out on the best possible solution.

GCC is the “de facto-standard open source compiler today” [1] according to LLVM.org and the foundation used to build complete systems – from the kernel upwards. GCC supports over 60 hardware platforms, including ARM, Intel, AMD, IBM POWER, SPARC, HP PA-RISC, and IBM Z, as well as a variety of operating environments, including GNU, Linux, Windows, macOS, FreeBSD, NetBSD, OpenBSD, DragonFly BSD, Solaris, AIX, HP-UX, and RTEMS. It offers highly compliant C/C++ compilers and support for popular C libraries, such as GNU C Library (glibc), Newlib, musl, and the C libraries included with various BSD operating systems, as well as front-ends for Fortran, Ada, and GO languages. GCC also functions as a cross compiler, creating executable code for a platform other than the one on which the compiler is running. GCC is the core component of the tightly integrated GNU toolchain, produced by the GNU Project, that includes glibc, Binutils, and the GNU Debugger (GDB).

“My all-time favorite GNU tool is GCC, the GNU Compiler Collection. At a time when developer tools were expensive, GCC was the second GNU tool and the one that enabled a community to write and build all the others. This tool single-handedly changed the industry and led to the creation of the free software movement, since a good, free compiler is a prerequisite to a community creating software.” —Dave Neary, Open Source and Standards team at Red Hat. [2]

Optimizing Linux

As the default compiler for the Linux kernel source, GCC delivers trusted, stable performance along with the additional extensions needed to correctly build the kernel. GCC is a standard component of popular Linux distributions, such as Arch Linux, CentOS, Debian, Fedora, openSUSE, and  Ubuntu, where it routinely compiles supporting system components. This includes the default libraries used by Linux (such as libc, libm, libintl, libssh, libssl, libcrypto, libexpat, libpthread, and ncurses) which depend on GCC to provide correctness and performance and are used by applications and system utilities to access Linux kernel features. Many of the application packages included with a distribution are also built with GCC, such as Python, Perl, Ruby, nginx, Apache HTTP Server, OpenStack, Docker, and OpenShift. This combination of kernel, libraries, and application software translates into a large volume of code built with GCC for each Linux distribution. For the openSUSE distribution nearly 100% of native code is built by GCC, including 6,135 source packages producing 5,705 shared libraries and 38,927 executables. This amounts to about 24,540 source packages compiled weekly. [3]

The base version of GCC included in Linux distributions is used to create the kernel and libraries that define the system Application Binary Interface (ABI). User space developers have the option of downloading  the latest stable version of GCC to gain access to advanced features, performance optimizations, and improvements in usability. Linux distributions offer installation instructions or prebuilt toolchains for deploying the latest version of GCC along with other GNU tools that help to enhance developer productivity and improve deployment time.

Optimizing the Internet

GCC is one of the most widely adopted  core compilers for embedded systems, enabling the development of software for the growing world of IoT devices. GCC offers a number of extensions that make it well suited for embedded systems software development, including fine-grained control using compiler built-ins, #pragmas, inline assembly, and application-focussed command-line options. GCC supports a broad base of embedded architectures, including ARM, AMCC, AVR, Blackfin, MIPS, RISC-V,  Renesas Electronics V850, and NXP and Freescale Power-based processors, producing efficient, high quality code. The cross-compilation capability offered by GCC is critical to this community, and prebuilt cross-compilation toolchains [4] are a major requirement. For example, the GNU ARM Embedded toolchains are integrated and validated packages featuring the Arm Embedded GCC compiler, libraries, and other tools necessary for bare-metal software development. These toolchains are available for cross-compilation on Windows, Linux and macOS host operating systems and target the popular ARM Cortex-R and Cortex-M processors, which have shipped in tens of billions of internet capable devices. [5]

GCC empowers Cloud Computing, providing a reliable development platform for software that needs to directly manages computing resources, like database and web serving engines and backup and security software. GCC is fully compliant with C++11 and C++14 and offers experimental support for C++17 and C++2a [6], creating performant object code with a solid debugging information.  Some examples of applications that utilize GCC include: MySQL Database Management System, which requires GCC for Linux [7]; the Apache HTTP Server, which recommends using GCC [8]; and Bacula, an enterprise ready network backup tool which require GCC. [9]

Optimizing Everything

For the research and development of the scientific codes used in High Performance Computing (HPC), GCC offers mature C, C++, and Fortran front ends as well as support for OpenMP and OpenACC APIs for directive-based parallel programming. Because GCC offers portability across computing environments, it enables code to be more easily targeted and tested across a variety of new and legacy client and server platforms.  GCC offers full support for OpenMP 4.0 for C, C++ and Fortran compilers and full support for OpenMP 4.5 for C and C++ compilers. For OpenACC, GCC supports most of the  2.5 specification and performance optimizations and is the only non-commercial, nonacademic compiler to provide OpenACC support.

Code performance is an important parameter to this community and GCC offers a solid performance base.  A Nov. 2017 paper published by Colfax Research evaluates C++ compilers for the speed of compiled code parallelized with OpenMP 4.x directives and for the speed of compilation time. Figure 1 plots the relative performance of the computational kernels when compiled by the different compilers and run with a single thread. The performance values are normalized so that the performance of G++ is equal to 1.0.

Figure 1. Relative performance of each kernel as compiled by the different compilers. (single-threaded, higher is better).

The paper summarizes “the GNU compiler also does very well in our tests. G++ produces the second fastest code in three out of six cases and is amongst the fastest compiler in terms of compile time.” [10]

Who Is Using GCC?

In The State of Developer Ecosystem Survey in 2018 by JetBrains, out of 6,000 developers who took the survey GCC  is regularly used by 66% of C++ programmers and 73% of C programmers. [11] Here is a quick summary of the benefits of GCC that make it so popular with the developer community.

  • For developers required to write code for a variety of new and legacy computing platforms and operating environments, GCC delivers support for the broadest range of hardware and operating environments. Compilers offered by hardware vendors focus mainly on support for their products and other open source compilers are much more  limited in the hardware and operating systems supported. [12]

  • There is a wide variety of GCC-based prebuilt toolchains, which has particular appeal to embedded systems developers. This  includes the GNU ARM Embedded toolchains and 138 pre-compiled cross compiler toolchains available on the Bootlin web site. [13] While other open source compilers, such as Clang/LLVM, can replace GCC in existing cross compiling toolchains,  these would need to be completely rebuilt by the developer. [14]

  • GCC delivers to application developers trusted, stable performance from a mature compiler platform. The GCC 8/9 vs. LLVM Clang 6/7 Compiler Benchmarks On AMD EPYC article provides results of 49 benchmarks ran across the four tested compilers at three optimization levels. Coming in first 34% of the time was GCC 8.2 RC1 using “-O3 -march=native” level, while at the same optimization level LLVM Clang 6.0 came in second with wins 20% of the time. [15]

  • GCC delivers improved diagnostics for compile time debugging [16] and accurate and useful information for runtime debugging. GCC is tightly integrated with GDB, a mature and feature complete tool which offers ‘non-stop’ debugging that can stop a single thread at a breakpoint.

  • GCC is a well supported platform with an active, committed community that supports the current and two previous releases. With releases schedule yearly this provides two years of support for a version.

GCC: Continuing to Optimize Linux, the Internet, and Everything

GCC continues to move forward as a world-class compiler. The most current version of GCC is 8.2, which was released in July 2018 and added hardware support for upcoming Intel CPUs, more ARM CPUs and improved performance for AMD’s ZEN CPU. Initial C17 support has been added along with initial work towards C++2A. Diagnostics have continued to be enhanced including better emitted diagnostics, with improved locations, location ranges, and fix-it hints, particularly in the C++ front end. A blog written by David Malcolm of Red Hat in March 2018 provides an overview of usability improvements in GCC 8. [17]

New hardware platforms continue to rely on the GCC toolchain for software development, such as RISC-V, a free and open ISA that is of interest to machine learning, Artificial Intelligence (AI), and IoT market segments. GCC continues to be a critical component in the continuing development of Linux systems. The Clear Linux Project for Intel Architecture, an emerging distribution built for cloud, client, and IoT use cases, provides a good example of how GCC compiler technology is being used and improved to boost the performance and security of a Linux-based system. GCC is also being used for application development for Microsoft’s Azure Sphere, a Linux-based operating system for IoT applications that initially supports the ARM based MediaTek MT3620 processor. In terms of developing the next generation of programmers, GCC is also a core component of the Windows toolchain for Raspberry PI, the low-cost embedded board running Debian-based GNU/Linux that is used to promote the teaching of basic computer science in schools and developing countries.

GCC was first released on March 22, 1987 by Richard Stallman, the founder of the GNU Project and was considered a significant breakthrough since it was the first portable ANSI C optimizing compiler released as  free software. GCC is maintained by a community of programmers from all over the world under the direction of a steering committee that ensures broad, representative oversight of the project. GCC’s community approach is one of its strengths, resulting in a large and diverse community of developers and users that contribute to and provide support for the project. According to Open Hub, GCC “is one of the largest open-source teams in the world, and is in the top 2% of all project teams on Open Hub.” [18]

There has been a lot of discussion about the licensing of GCC, most of which confuses rather than enlightens. GCC is distributed under the GNU General Public License version 3 or later with the Runtime Library Exception. This is a copyleft license, which means that derivative work can only be distributed under the same license terms. GPLv3 is intended to protect GCC from being made proprietary and requires that changes to GCC code are made available freely and openly. To the ‘end user’ the compiler is just the same as any other; using GCC makes no difference to any licensing choices you might make for your own code. [19]

Notes

 3. Information provided by SUSE based on recent build statistics. There are other source packages in openSUSE that do not generate an executable image and these are not included in the counts.


Margaret Lewis is a technology consultant who previously served as Director of Software Planning at AMD and an Associate Director at the Maui High Performance Computing Center.

Thanks to the GCC Steering Committee and GNU Cauldron participants for their support and feedback on early drafts of this paper.
